Camera Oneking USB 3.0 HD910-U30-K2
Mô tả ngắn
HD910-U30-K2,10x Optical zoom, UVC USB 3.0 Video PTZ Camera, 720P/1080P
2.0 Megapixel, Full HD Camera experience 1080i@60 vivid images, equipped with 10x optical zoom lens.
Hotline: 0918 642 886
HD910-U30-K2,10x Optical zoom, UVC USB 3.0 Video PTZ Camera, 720P/1080P
2.0 Megapixel, Full HD Camera experience 1080i@60 vivid images, equipped with 10x optical zoom lens, enhancing your video conferencing, distance learning, training meeting, courtrooms or remote medical with natural and smooth video images. USB3.0 Interface is easy to installation and transfer high-quality video streaming. Features: Private Tooling design High Definition PTZ camera Fast and smooth video handling Power ON-OFF switch Work & Standby LED indicator Speed Match Auto/Manual focus/brightness/WB RS-232C/VISCA Protocol Lens/Dome OSD menu Boundary scanning Standby & wakeup status Swap ,video format button USB 3.0 Video output.
|
Model |
HD910-USB-K2 |
|
|
Image SenSor |
Sensor |
1/3” model, primary color CMOS, 2.1 M compatible |
|
Minimum Scene lllumination |
0.1Lux |
|
|
White Balance |
AUTO/Manual |
|
|
Gain Control |
AUTO |
|
|
Back-light compensation |
ON/OFF |
|
|
Electronic shutter |
1/30s~1/10,000s |
|
|
S/N Ratio |
>50db |
|
|
Lens |
Focus |
AUTO |
|
Iris |
AUTO/Manual |
|
|
Zoom |
10 X Optical ZOOM |
|
|
f=5mm～50mm F2.0(W)～2.8(T) |
||
|
Video Output |
USB 3.0 Interface |
|
|
YUY2 |
||
|
Video format |
YUY2 | 1920x1080 30p, 1280x 720 30p |
|
|
Control Decoder |
EIA/RS-485 |
|
|
Communication |
EIA/RS-232(Bidirectional) |
|
|
PTZ Control Protocol |
VISCA,PELCO-P,PELCO-D |
|
|
Baud Rate |
4800/9600 bps |
|
|
Patrol tours |
4 |
|
|
Preset |
64 |
|
|
Save status after Power off |
Support |
|
|
Speed Matching Function |
Support |
|
|
OSD Menu |
Support |
|
|
Image Auto Flip |
Support |
|
|
Pan Speed |
0-100 degrees/s |
|
|
Tilt Speed |
0-80 degrees/s |
|
|
Pan Rotation Angle |
359degrees |
|
|
Tilt Rotation Angle |
240degrees |
|
|
Auto Pan Scan |
Support |
|
|
Boundary Scan |
0-359degrees(Programmable) |
|
|
Remoter Control |
IR Wireless remote control P/T/Z |
|
|
Power |
DC12V ±10% 1.2A |
|
|
Operation Temperature |
-10℃～60℃ |
|
|
Environmental humidity |
0-95%RH(non-condensation) |
|
|
Length X width X high |
124x120x145mm/220x175x220mm(NET/PACKAGE) |
|
|
Weight |
800g/1300g(NET/PACKAGE)
|
|
