1 x 240W @ 70V/100V
2 x 120W @ 4/8 Ω
Line–level output
2ch Dante input & Stereo Line level input
Built–in DSP
Controllable via RS–232 and IP
Auto standby
PA−240Net is a high−performance, selectable Hi−Z (70V/100V) or Lo−Z (4Ω/8Ω) power amplifier featuring balanced and unbalanced inputs and additional line−level output and Dante interface. This versatile amplifier features built−in DSP, auto−standby and maximum durability. PA−240Net is suitable for a vast range of AV installations.

INPUTS
2 Channels, on a Dante™ Net: On an RJ–45 connector
1 Balanced Stereo Audio: +4dBu/10kΩ, on a 5 pin terminal block
OUTPUTS
1 Balanced Stereo Audio: Line level, on a 5–pin terminal block
1 Speaker: On a 4–pin large terminal block
PORTS
1 Control via IP: On an RJ–45 connector
1 RS-232: On a 3–pin terminal block
AMPLIFIER
Input Sensitivity: Full power @ 0.3V (–10dBV)
Output Power: 2 x 120W @ 4Ω or 8Ω, 1 x 240W @ 70V or 100V
Class: D
Maximum Voltage Gain: 26dB SE / 32dB BTL
Dynamic Range: 119dB
Frequency Response: 20Hz to 20kHz @ +/–1dB
S/N Ratio: 80dB, 20Hz — 20kHz
Audio THD + Noise: THD+N (1kHz @ 1W) 0.003 %
Audio 2nd Harmonic: 0.08% @ 75W RMS @ 4Ω 6.67kHz
USER INTERFACE
Controls: Output volume attenuator, IP and RS–232
POWER
Source: Universal mains operational voltage 85V AC — 265V AC (full power at 120V — 230V)
Consumption: 265VA
Total System Efficiency: 90%
ENVIRONMENTAL CONDITIONS
Operating Temperature: 0° to +40°C (32° to 104°F)
Storage Temperature: –40° to +70°C (–40° to 158°F)
Humidity: 10% to 90%, RHL non–condensing
REGULATORY COMPLIANCE (STANDARDS COMPLIANCE)
Safety: CE, FCC
Environmental: RoHs, WEEE
ENCLOSURE
Size: ½ 19” desktop
Type: Aluminum
Cooling: Fan ventilation
ACCESSORIES
Included: Power cord
PRODUCT DIMENSIONS
21.46cm x 16.30cm x 4.36cm (8.45" x 6.42" x 1.72" ) W, D, H
PRODUCT WEIGHT
1.1kg (2.3lbs) approx.
