Camera Telycam Meet+ 10-U3 TLC-1000-U3-10P
Mô tả ngắn
Meet+ 10-U3 USB PTZ Camera for Middle and Small Meeting Room
1080p60 high-definition image
10x optical zoom
62.5-degree FOV
Power via USB3.0 port
Hotline: 0918 642 886
Meet+ 10-U3 USB PTZ Camera for Middle and Small Meeting Room
Features:
- High-definition image
Equipped with advanced image processing solution and cutting-edge video camera algorithms, a 1/2.8 inch sensor and high-quality lens, to output crystal clear image, max up to 1080p60 full high definition resolution.
- 10x optical zoom
Uses truly 10x optical zoom lens, with 62.5-degree wide angle FOV, fast and accurate focus performance to capture details in large and middle room
- Easy operation
Matched with IR remote controller, to control PTZ movement, 10 presets and adjust functions as preference in the OSD menu
- Smooth and quite PTZ movement
Smart, compact and decent mechanism, to bring smooth, silent and accurate PTZ movement, to make sure everyone is participated in the meeting.
- Plug and play
USB3.0 video output 1080p60 resolution, plug and play, work with any of your favorite video conferencing software
- Power via USB3.0 port
Meet+ 10-U3 can power via a USB3.0 port directly, with no need for the power supply adaptor, which makes deployment even more simple, a single cable enables power, video, and control.
Technical Specifications:
|
Camera |
Meet+ 10-U3 |
|
Item Number |
TLC-1000-U3-10P |
|
Sensor |
1/2.8 inch high quality, CMOS Sony sensor |
|
Video Resolution |
USB3.0： YUY2：1920*1080P60;1280*720P60；1024*576P60；640*480P60；640*360P60； USB2.0： YUY2: 1280*720P25；1024*576P30/25；640*480P50/30/25；640*360P60/50/30/25 |
|
Lens Zoom |
10x optical zoom, 12x digital zoom |
|
Focal length |
f＝4.7(wide)～47mm(Tele), F1.6~F3.0 |
|
View Angle |
62.5° (wide)~ 6.43° (Tele) |
|
Vertical viewing angle |
40.1° ~ 4.1° |
|
Diagonal viewing angle |
69.7° ~ 7.56° |
|
Minimum Object Distance |
Wide: 0.5m; Tele: 1m |
|
SNR |
>50dB |
|
Image parameter |
|
|
Noise Reduction |
2D/3D |
|
Minimum LUX |
0.7lux (50 IRE Max AGC,1/30,F1.8) |
|
White Balance |
Auto/Manual/Indoor/Outdoor/Push/Sodium/Fluorescent |
|
Focus |
Auto / Manual |
|
Iris |
Auto / Manual |
|
Electronic Shutter |
Auto / Manual |
|
BLC |
Supported |
|
Mechanism |
|
|
Pan Rotation Angle |
-170° ~ +170° |
|
Tilt Rotation Angle |
-30° ~ +90° |
|
Pan Rotation Speed |
0°~120°/s |
|
Titl Rotation Speed |
0°~80°/s |
|
Preset |
128 presets via RS232, 10 presets via remote controller |
|
Control |
RS232/RS485/USB/Remote Controller |
|
Video Port: |
USB3.0 |
|
General |
|
|
Input voltage |
5V 1000mA(via USB 3.0)/ DC: 12V 2A(via Power Adapter) |
|
Power Consumption |
DC: 12V 2A (Pmax=7W) |
|
Operating Temperature |
-10℃~ 50℃ |
|
Operating Humidity |
≤80% |
|
Color |
Silver |
|
Camera Dimension |
148mm×132mm×162mm |
|
Package Dimension |
28x24x24cm |
|
Package Content |
Camera, Remote Controller, RS232 cable, USB3.0 cable, Power Supply |
