Ismart 1080P PTZ Camera AMC-G320U3
Mô tả ngắn
Ismart 1080P PTZ Camera AMC-G320U3
1/2.8” CMOS, 2.14MP excellent 1080P video quality;
20x optical zoom, 16x digital zoom;
HDMI, USB3.0 and Ethernet video outputs;
Hotline: 0918 642 886
The new AMC-G320U3 USB 3.0 PTZ camera employs the latest image technology for 1080P HD video quality, with excellent color reproduction, quick focus. It’s an ideal choice for various HD video capture applications.
Features:
- 1/2.8” CMOS, 2.14MP, excellent 1080P video quality.
- Quick focus to ensure superb clarity;
- High color reproduction, presenting real and vivid color with more details.
- HDMI, USB3.0 and Ethernet video outputs；
- RS-232 in and RS-232/RS-485 out, with available daisy chain.Compact design, easy for installation and connection；
- Compact remote control with comfortable user experience.
|
Model |
AMC-G320U3 |
|
Camera |
|
|
Image Sensor |
1/2.8” CMOS，2.14MP |
|
IRIS |
4.7mm～94mm |
|
Focal Length |
F1.6～F3.5 |
|
Field Of View |
59.5°～2.9° |
|
Optical zoom |
20x |
|
Digital Zoom |
16x |
|
Focusing System |
Auto/Manual/One Push/PTZ |
|
Min Illumination |
1.0Lux |
|
Shutter Speed |
1/50-1/10,000s |
|
Gain |
Auto, Manual |
|
White Balance |
Automatic, Manual, Automatic tracking, One Push, Static Color Temperature |
|
BLC |
Support |
|
Wide Dynamic |
Support |
|
Exposure |
Auto, Manual, Shutter Priority, Iris Priority, Brightness Priority |
|
S/N Ratio |
≥50dB |
|
PTZ |
|
|
Pan Range |
-170°~+170° |
|
Tilt Range |
-30°~+90° |
|
Pan Speed |
0.1°~102°/s |
|
Tilt speed |
0.1°~90°/s |
|
Ceiling Mount |
Support |
|
Presets |
255 |
|
Interface |
|
|
HDMI |
1 Channel HDMI ； Video resolution:1080P60/P50/P30/P25, 720P60/P50/P30/P25, 480P60/P50/P30/P25 |
|
Network |
1×RJ-45: 1×10M/100M 1. Video Output Format: Max 1080P60 2. Image Compression:H.264/H.265 3. Protocol: ONVIF/RTSP/RTMP/SRT/TCP/UDP 4. Audio Compression: AAC 5. Support Dual streams |
|
USB |
1×USB3.0： 1. Support UVC1.1 2. UVC Support: H.264/H.265/MJPEG, Video resolution:1080P60/P50/P30/P25， 720P60/P50/P30/P25, 480P60/P50/P30/P25, 360P60/P50/P30/P25 YUY2/NV12, Video resolution:1080P30/P25, 720P30/P25, 480P30/P25, 360P30/P25 3. UAC Audio Format PCM |
|
Audio |
1×LINE In, 3.5mm |
|
Control Interface |
1×RS-232 In, 1×RS-232 Out/RS-485 |
|
Power |
DC12V |
|
General |
|
|
Control Protocol |
VISCA / PELCO-P / PELCO-D |
|
Power |
＜15W |
|
Working Temperature |
0 ~ 40°C |
|
Storage Environment |
-20℃ ~ 40°C |
|
Relative Humidity |
10%RH ~ 90 %RH |
|
Dimensions (L×W×H) |
176mm × 137mm × 171mm |
|
Weight |
≤1.2kg |
