Inogeni 4KX-PLUS HDMI 4K to USB
Mô tả ngắn
Inogeni 4KX-PLUS HDMI 4K to USB
HDMI capture to USB 3.0
Compatible with USB 2.0 (high-quality MJPEG)
HDMI loop output
Up to Ultra HD 4K (3840/4096×2160) at 30 fps and 1080p at 60 fps
Hotline: 0918 642 886
INOGENI’s 4KX-PLUS Ultra HD to USB 3.0 camera converter with an HDMI loop and external power is the most cost-effective and high-performance professional camera converter for your BYOM applications. It connects your HDMI cameras, video sources and CODECS to your laptop.
- Perfectly compatible with Cisco Webex BYOM applications
- Direct integration with Cisco room equipment (camera, audio and screen)
- Solves interoperability issues
- Optimizes your assets and avoids additional license fees for Cloud Video Interop (CVI) service and user management
- Compact and robust camera converter technology
- Designed and manufactured in Canada
- TAA-compliant
|
HDMI Input |
|
|
Connector |
1 x HDMI 1.4a |
|
Video Resolutions |
4K UHD (3840/4096x2160), 1440p, 1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960,1280x800, 1024x768, 800x600, 640x480 |
|
Frame Rates |
60, 59.94, 50, 30, 29.97, 25, 24, 23.98 Hz for all resolutions, except 4K = 30Hz max. |
|
Color Space |
RGB, YCbCr, 4:4:4, and 4:2:2 (4K=RGB) |
|
Sampling Rate |
297 MHz |
|
Embedded Audio |
Ch 1&2 48kHz LPCM |
|
HDCP Copy Protection |
INOGENI will not decrypt BD/DVD movies, satellite/cable receivers or other HDCP encrypted sources. |
|
HDMI Output |
|
|
Connector |
1 x HDMI 1.4a |
|
Video Resolutions |
Same as HDMI input |
|
Frame Rates |
Same as HDMI input |
|
Color Space |
Same as HDMI input |
|
Sampling Rate |
Same as HDMI input |
|
Embedded Audio |
Same as HDMI input |
|
HDCP Copy Protection |
Same as HDMI input |
|
USB |
|
|
Connector |
1 x USB type B (USB 3.0/2.0) |
|
Video Format (USB3) |
Uncompressed, YUY2 4:2:2 or NV12/I420 4:2:0 (configurable) |
|
Video Format (USB2) |
MJPEG |
|
Video Resolutions |
4K UHD (3840/4096x2160), 1440p, 1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960,1280x800, 1024x768, 800x600, 640x480 |
|
Video Scaler |
Automatic hardware based |
|
Color Space Conversion |
Automatic hardware based |
|
Sampling Conversion |
Automatic hardware based |
|
Frame Rate Conversion |
Automatic hardware based |
|
Audio |
|
|
Audio Input |
1 x 3.5mm analog audio jack (MIC or LINE level) |
|
Audio Output |
1 x 3.5mm analog audio jack (LINE level) |
|
Mixing Functionality |
HDMI audio and analog audio inputs are mixed over the USB input interface. USB audio output and HDMI audio input are mixed over the analog audio output. Use Control App in order to manage audio layout. |
|
Compatibility |
|
|
Dimensions & Weight |
99mm x 70mm x 24mm, 129g |
|
Operating Temperature |
0° to 45° C (32° to 113° F) |
|
Storage Temperature |
-40° to 105° C (-40° to 221° F) |
|
Relative Humidity |
0% to 90% non-condensing |
|
Power |
Powered by USB (5V, 900mA) or by external power supply (5V, 900mA). |
