Inogeni CAM230 Switch 1 of 3 USB/HDMI cameras to USB or HDMI
Change camera and video configurations without interrupting the presentation
Ideal for remote education, collaborative meetings, webinars, and live-streaming
Cost-effective, reliable, and easy to install and connect (no drivers required)
3 video sources clean switcher into a single video flow
The INOGENI CAM230 is a USB and HDMI multi-camera switcher that helps improve meeting equity in virtual meetings. With its easy-to-use camera switching capabilities and support for bidirectional audio with videobars, facilitators can ensure that all participants have equal opportunities to speak and contribute.
The CAM230 also supports whiteboard and document cameras for added collaboration and productivity.
- 3 video sources (2x USB 3.0/2.0 and 1x HDMI) clean switcher into a single video flow
- Video output for CODECs, matrixes, monitors or laptops for BYOM settings HDMI 2.0, USB 2.0 MJPEG – 1080p30
- Instantly change camera and video configurations without interrupting the presentation
- Ideal for remote education, collaborative meetings, webinars, and live-streaming
- Controllable by RS-232 and IP - Switch the camera via your videoconferencing pad or with the push button
- Audio I/O via the INOGENI Control App
- Cost-effective, reliable, and easy to install and connect (no drivers required)
- Compact and robust design with an aluminum enclosure
- Designed and manufactured in Canada
- TAA-compliant

SPECIFICATIONS:
|
Physical details |
|
|
|
Dimensions (W x L x H) |
17.33 cm x 11.57 cm x 3.26 cm 6.82” x 4.55” x 1.28” |
|
|
Power supply |
12V (100-240 VAC 50/60Hz to 12V/1.2A DC) – or – PoE source compliant with IEEE 802.3af (802.3at Type 1) |
|
|
Weight |
606 g |
|
|
Package content |
1 x USB 2.0 Type-B to Type-A cable (3ft). 1 x terminal block connection. 1 x 12V power supply. |
|
|
Operating temperature |
0° to 45° C (32° to 113° F) |
|
|
Storage temperature |
-40° to 105° C (-40° to 221° F) |
|
|
Relative humidity |
0% to 90% non-condensing |
|
|
UPC code |
51497302825 |
|
|
Origin |
Canada |
|
|
Warranty |
2 years |
|
|
USB inputs |
|
|
|
2x USB 3.0 inputs |
1x USB 3.0/2.0 camera Uncompressed, YUYV/NV12/I420 – 1080p50/60, 4K30 MJPEG – 1080p30 |
|
|
HDMI input |
|
|
|
Resolution |
1080p50/60 fps, 720p50/60 fps |
|
|
Connector |
HDMI |
|
|
HDMI output |
|
|
|
Resolution |
3840x2160p23.98/24/25/29.97/30 fps, 1080p50/60 fps, 720p50/60 fps |
|
|
Connector |
HDMI |
|
|
USB 2.0 output |
|
|
|
USB-B Type-B connector |
Device will expose a UVC interface over USB 2.0 up to 1080p30 MJPEG with a digital audio input and output interfaces |
|
|
Audio |
|
|
|
Digital audio I/O |
Embedded in HDMI or USB |
|
|
Control |
|
|
|
Control options |
Front buttons RS-232 LAN USB |
|
|
IP interface |
100 Mbps |
|
|
RS232 interface |
Baud rate: 9600 Data bits: 8 Stop bits: 1 Parity: None Flow control: None |
|
Inogeni CAM300 Switch 1 of 4 USB/HDMI cameras to USB 3.0
Switch between 2 USB and 2 HDMI sources: 2x USB camera, MJPEG or H264, 2x HDMI 1080p60
Outputs to an uncompressed 1080p60 USB 3.0 and HDMI connection
Control interface: LAN, RS-232, USB
Embedded audio in USB and HDMI and line level stereo audio support
