Inogeni SHARE2 Mix 2 HDMI-DVI cameras to USB 3.0
Mô tả ngắn
Inogeni SHARE2 Mix 2 HDMI-DVI cameras to USB 3.0
2 HDMI cameras mixer into a single USB 3.0 interface
Engage a dynamic presentation and easily switch up to 14 mix setup videos
Change camera and video configuration without cutting the flow of your presentation
Hotline: 0918 642 886
INOGENI’s easy and versatile SHARE2 Camera Mixer provides Picture-In-Picture in one video flow. Create interactive presentations for collaborative meetings and HyFlex classrooms.
- 2 HDMI cameras mixer into a single USB 3.0 interface
- Engage a dynamic presentation and easily switch up to 14 mix setup videos
- Change camera and video configuration without cutting the flow of your presentation
- Ideal for remote education, collaborative meetings, webinars or live streaming
- Compatible with the Q-SYS Core processors
- Output: Uncompressed video on USB 3.0 or MJPEG on USB 2.0
- Audio I/O and mixer via the INOGENI Control App
- Controllable by LAN & RS-232
- Cost-effective solution that is reliable and simple to install and connect (no driver required)
- Compact and robust design with its aluminium enclosure
- Designed and manufactured in Canada
Specs:
|
Video Input 1 |
|
|
Connector |
1x HDMI |
|
Video Resolutions |
1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480 |
|
Video Input 2 |
|
|
Connector |
1x DVI-I – (Digital & Analog). |
|
Video Resolutions |
DVI: 1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480 VGA: 1080p, 720p, 480p, 576p, 1920x1200, 1680x1050, 1400x1050, 1600x1200, 1280x1024, 1360x768, 1280x768, 1280x800, 1024x768, 800x600, 640x480 Component: 1080p, 1080i, 720p, 480p, 480i, 576p and 576i CVBS: 480i, 576i [Available on green connection of a DVI to Component adapter] |
|
Frame Rates |
Up to 60 Hz, all formats. |
|
Color Space |
RGB, YCbCr 4:4:4 and 4:2:2. |
|
Sampling Rate |
165 MHz |
|
Analog input |
Analog stereo, line level, 3.5mm jack. |
|
Analog output |
Analog stereo, line level, 3.5mm jack. |
|
HDCP Copy protection |
The device will not decrypt BD/DVD movies, satellite/cable receivers or other encrypted sources. |
|
Mixer Control |
The Mixer feature can be controlled by the following interfaces: HID RS-232 Keypad INOGENI REMOTE LAN |
|
Compatibility |
|
|
Operating System |
NO driver installation necessary. Windows 7 and above (32/64-bit) macOS 10.10 and above Linux (kernel v2.6.38 and above) Android |
|
Host Requirements |
USB 3.0 port Minimum 4GB RAM Intel Core i5 Graphic card with its own memory for on-screen rendering applications. |
|
Motherboard |
Compatible with all motherboards: Intel, Renesas, ASMedia, and Fresco Logic. |
|
Cameras Supported |
Cameras and camcorders with an HDMI/DVI, VGA or CVBS output. |
|
Software Compatibility |
UVC-compliant. Runs with all software compatible to DirectShow, V4L2, QuickTime and AVFoundation. |
|
Dimensions [W x L x H, cm] |
18.5 x 11 x 3 |
|
Weight [g] |
530 |
|
Power |
12V, 500mA (adapter included) |
