Camera Telycam Meet bar TLC-800-U2-4K
Mô tả ngắn
Zoom: 4x digital zoom
View Angle: 120 degree
Video Interface: Type C
Video Resolution: 4K30
Color: black, white
Hotline: 0918 642 886
Meet bar
TLC-800-U2-4K integrates a premium camera, microphone, and speakers into an All-in-One unit for a face-to-face video conferencing experience. The camera's 120-degree wide-angle captures every participant in the conference room in high definition; The exclusive audio algorithm allows every word of the participant to be heard; The flexible and easy installation simplifies conference room deployment, truly plug-and-play.
See Everyone Clearly
- Adopts advanced image processing solution, 1/2.8” 8.5MP CMOS sensor, and high quality 4K lens with 120-degree FOV, to provide sharp and crystal clear image.
- Max resolution 2160p30 (MJPG/H.264/H.265) is supported.
- 4x electronic zoom adjustable.
- Auto-frame participants at meeting
- Type C USB port output high and low video resolution for different applications scalable.
Hear Everyone Clearly
- Adopts beamforming microphone, and uses microphone array algorithms
- 360°Omni-directional and 5 meters voice pickup
- Full duplex communication
- 384ms acoustic echo cancellation and background noise suppression
- Auto-level loud and soft voices
- The peak-limiting algorithm eliminates even momentary speaker clipping to prevent distortion
Install and Operate Easily
- Comes with a mounting bracket, which can be placed above or below the monitor, or on the desktop of a conference room.
- Audio and video integration, reduce wiring, simplify installation, USB plug and play
- Configured with remote control, users can set functions according to their preferences and needs
- Built-in standard UVC protocol, which can be used with any conferencing software you like.
|
Video |
|
|
Sensor |
1/2.5”CMOS sensor |
|
Effective Pixel |
8.5M effective pixels 16:9 |
|
Scan |
Progressive |
|
LENS |
f=2.22mm±5% |
|
Iris |
F=2.4±5% |
|
FOV |
120° |
|
Focus Mode |
Fixed |
|
WhiteBalance |
ATW/Auto/Manual/Outdoor/Indoor/Sodium/Fluorescent/OnePush |
|
Iris |
Auto/Manual/Brightness Priority/Shutter Priority |
|
Anti-Flicker |
OFF/50Hz/60Hz |
|
Noise Reduction |
2D & 3D |
|
Wide Dynamic |
Support |
|
Backlight compensation |
Support |
|
Color Enhancement |
Support |
|
Edge Enhancement |
Support |
|
Image Flip |
Support |
|
Image Mirroring |
Support |
|
Electronic Pan/Tilt |
Support |
|
Auto Frame |
Support |
|
Remote Controller |
2.4G remote controller to set OSD menu, audio, mute, video |
|
USB Port |
Type C |
|
Protocol |
UVC1.0~1.5 |
|
Video Format |
MJPG/H.264/H.265/YUY2 |
|
Resolution |
MJPG/H.264/H.265: 3840x2160, 2592x1944, 2048x1536, 1920x1080, 1600x1200, 1280x1024, 1280x720, 1280x960, 1024x768, 800x600, 720x576, 704x576, 640x480, 640x360, 352x288, 320x240, 320x180 YUV:1280x720, 1280x960, 1024x768, 800x600, 720x576, 704x576, 640x480, 640x360, 352x288, 320x240, 320x180 |
|
Frame |
30FPS/25FPS/20FPS/15FPS/10FPS/5FPS |
|
Audio |
|
|
Audio Input/ Output |
Built-in Omni-directional microphone array |
|
Protocol |
UAC |
|
Microphone |
4pcs Omni-directional microphone |
|
Speaker |
4Ω/8W 100-24KHz 2 inch anti-magnetic horn |
|
Pickup bandwidth |
100-16KHz |
|
Sampling frequency |
32KHz(Ascending), 48KHz(Descending) |
|
Sensitivity |
-38dB~94dB SPL@1KHz |
|
S/N ratio |
65dB 94dB SPL@1KHz |
|
Audio Feature |
Auto acoustic echo cancellation, Auto gain, Auto background noise suppression, Full-duplex, 360°Omni-directional pickup, Array Microphone algorithms |
|
Pickup range |
3~5meters, ideal within 3 meters |
|
Others |
|
|
Operation System |
Windows7/8/10, MAC OS 10.7 and above, Android, Linux |
|
RJ45 |
Only used for control and firmware upgrade |
|
Power Consumption |
12V/500Ma, power adapter |
|
Dimension |
φ70.5×φ70.5×370.7mm |
|
Work Temperature |
0°~40°C |
|
StorageTemperature |
-40°~70°C |
|
Color |
Metal Silver |
