Camera Telycam Vision+ FN 20X
Mô tả ngắn
1080p60 FHD video resolution
20x Optical Zoom
NDI ®, HDMI, 3G-SDI, USB-C video interface, Line in audio interface
NDI® 5 Integrated
Power over Ethernet
Hotline: 0918 642 886
Camera Telycam Vision+ FN 20X Features:
1080p60 Full HD Resolution
Vision+ FN is equipped with the most advanced image processing solution and 1/2.8-inch 2.4MP image sensor, to achieve smooth, sharp and crystal-clear FHD 1080p60 images, even in the low-light working environment.
20x Optical Zoom
Shooting with 20x optical zoom & 12X electronic digital zoom and a 60° horizontal angle of view.
3G-SDI/HDMI/USB2.0 Available
In addition to NDI ®, 3G-SDI, HDMI and USB2.0 output image simultaneously as well. 3G-SDI and HDMI are for conventional video production workflow, and USB output can be used as a high-end webcam.
Full NDI® Integrated
High bandwidth NDI® transmits full HD video at a maximum of 125 Mbps, enabling high-quality, low-latency live video transmission.
With high bandwidth NDI®, Vision+ FN presents very less image compression and low latency for live video production, with almost the same performance as HDMI output.
|
Camera |
Vision+ FN 10x |
Vision+ FN 20x |
|
Part Number |
TLC-300-IP-10-FNDI |
TLC-300-IP-20-FNDI |
|
Sensor |
1/2.8 inch, 2.4MP CMOS Sensor |
|
|
Zoom |
10x optical zoom |
20x optical zoom |
|
Lens |
f = 4.9 ~ 49mm, F1.5 ~ F3.0 |
f =4.9 ~ 98mm, F1.5 ~ F3.0 |
|
Horizontal View Angle |
60°(Wide) ~ 3.2°(Tele) |
60° (Wide) ~ 3.2° (Tele) |
|
Vertical viewing angle |
32.2°~ 1.8° |
|
|
Diagonal viewing angle |
61°~ 3.64° |
|
|
Minimum Working Distance |
Wide: 1m; Tele: 1.5m |
|
|
S/N Ratio |
≥50dB |
|
|
Video Format |
HDMI： 1920*1080P60/59.94/50/30/29.97/25/24/23.98; 1920*1080I60/59.94/50 1280*720P60/59.94/50/30/29.97/25 |
|
|
Full NDI®： 1920*1080P60/59.94/50/30/29.97/25/24/23.98; 1920*1080I60/59.94/50 1280*720P60/59.94/50/30/29.97/25 |
||
|
3G-SDI： 1920*1080P60/59.94/50/30/29.97/25/24/23.98 1920*1080I60/59.94/50 1280*720P60/59.94/50/30/29.97/25 |
||
|
USB Type-C： YUY2: 1920*1080P6; 1280*960P10; 1280*720P13; 1024*768P15; 800*600P25; 640*480P30; 640*480P30 MJPG: 1920*1080P30; 1280*960P30; 1280*720P30; 1024*768P30; 800*600P30; 640*480P30; 640*480P30 |
||
|
Image Parameters |
||
|
Noise Reduction |
2D&3D |
|
|
Minimum lux |
0.7Lux (50 IRE Max AGC,1/30, F1.8) |
|
|
White Balance |
Auto/Manual/Auto tracking/Push/Indoor/Outdoor/Color Temperature |
|
|
Exposure |
Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority |
|
|
Anti-Flicker |
OFF,50Hz,60Hz |
|
|
Image Flip |
Support |
|
|
Mirroring |
Support |
|
|
Focus |
Auto/Manual |
|
|
Iris |
Auto/Manual |
|
|
Electronic-shutter |
Auto/Manual |
|
|
Gamma |
Support |
|
|
WDR |
Support |
|
|
Backlight Compensation |
Support |
|
|
IP Streaming |
||
|
Video Encoding |
H.264 |
|
|
Video Bitrate |
6Mbps ~ 135Mbps |
|
|
Bitrate Control |
Variable bitrate(VBR), Constant bitrate(CBR) |
|
|
Network Port Speed |
1000M |
|
|
Protocol |
NDI®, TCP, HTTP, VISCA over IP(TCP&UDP), HTML5, VISCA, PELCO P/D |
|
|
Pan/Tilt Movement |
||
|
Preset |
Remote controller: 10; Serial port: 128; Accuracy：0.1° |
|
|
Pan Rotation Angle |
-170° ~ +170° |
|
|
Tilt Rotation Angle |
-30° ~ +90° |
|
|
Pan Rotation Speed |
0.1° ~ 120°/s |
|
|
Tilt Rotation Speed |
0.1° ~ 80°/s |
|
|
I/O Interface |
||
|
Control Port |
RS232、RS485、RJ45 (VISCA over IP)、USB2.0(UVC) |
|
|
Video Port |
NDI®, HDMI, 3G-SDI, USB2.0(Type-C) |
|
|
Audio Port |
Dual 3.5mm linear inputs |
|
|
Tally |
Support |
|
|
POE+ |
Support |
|
|
Daisy Chain |
Support |
|
|
General |
||
|
Input Voltage |
DC: 12V 2A (Pmax=11W), POE+: IEEE802.3at(Pmax=11W) |
|
|
Operating Temperature |
-10℃~ 50℃ |
|
|
Operating Humidity |
≤80% |
|
|
Color |
Black/White |
|
|
Dimension（L×W×H） |
220mm×190mm×173mm |
|
|
Net Weight |
1.45kg(3.3LBS) |
|
